1500ml Automatic PET Blowing Machine 3000BPH Plastic Bottle

Brand Name : Eceng

Model Number : q3000

Certification : CE ISO

Place of Origin : Jiangsu, China

MOQ : 1set

Price : $26,800.00/Sets 1-1 Sets

Payment Terms : L/C, T/T, Western Union

Supply Ability : 500 Set/Sets per Year

Delivery Time : 35days

Packaging Details : standard export wooden case or according to your requirements

Plastic Processed : PET

Voltage : 380V,50HZ

Hollow part volume : 2l

Warranty : 1 Year

Automatic : Yes

output : 3000-3500

Weight : 2.5 tons

Contact Now

3000BPH fully automatic 1500ml juice coco cola plastic pet bottle blow moulding molding machine price


1500ml Automatic PET Blowing Machine 3000BPH Plastic Bottle
specification
Item
Q3000
Bottle type specification
Cavity
2
Theory output
3500
Max.volume
2L
Bottle mouth maximum overall diameter
80mm
Bottle biggest diameter
100mm
Bottle maximum height
330mm
Power specification
Light tube quantity
32pcs
Light tube power
0.75KW
Maximum heating power
24KW
All electric machine installation
27KW
Actual consumption
19KW
Air pressure specification
Work pressure
7-9kg/cm2
Low-pressure gas consumption
1000L/min
Blow bottle pressure
25-35kg/cm2
Higher -pressure gas consumption
1500Ltr/min
Air pressure specification
Work pressure
5-6 kg/cm2
Temperature range
10℃
Consumption
5000kcal/hr
Frozen water flow
30L/min
Machine specification
Machine size
2.25x1.6x1.7
Machine weight
2.5ton
1500ml Automatic PET Blowing Machine 3000BPH Plastic Bottle
Q series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 2 cavity to 9 cavity with a speed of 1000 bottles per hour (500 ml plastic bottles),max volume 2L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.
Detailed Images
1500ml Automatic PET Blowing Machine 3000BPH Plastic Bottle

1500ml Automatic PET Blowing Machine 3000BPH Plastic Bottle
Q linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type. Q series linear bottle blowing machine features: 1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system. 2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety. 3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs. 4. manual and automatic methods of operation, human-machine interface control, simple operation. 5. servo transmission system, high positioning accuracy, fast speed stability and good reliability. 6. less than 0.2% scrap rate for finished bottle .
1500ml Automatic PET Blowing Machine 3000BPH Plastic Bottle
our advantage
1. Resonable price
2. Good after service
3. experienced skilled workers and professional engineers
4. Good quality ,excellent service ,long life mould
5. on time delivery time
6.our engineers can be online for 24 hours to serve you
Company Introduction
1500ml Automatic PET Blowing Machine 3000BPH Plastic Bottle
Packing&Shipping
1500ml Automatic PET Blowing Machine 3000BPH Plastic Bottle
After Sales Service
1.Installation, debug
We will arrange seasoned technician for debug and test production at the same time make the equipment reach the rated producing capacity of the line.
2. Training
Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.
3.the sample service
1'We can send you the video of the running machine.
2'You are welcome to come to visit our factory,and see the machine running.
4.We can design the machines according your requirements,at the same time we will give you our professional suggestion,as you know,we have been in this industry for 12 years.
5.well-trained & experienced staff are to answer all your inquiries in English and Chinese
6 .12 Months guarantee and life-long technical support.
7.Your business relationship with us will be confidential to any third party.
8. Good after-sale service offered, please get back to us if you got any questions.


1500ml Automatic PET Blowing Machine 3000BPH Plastic Bottle
FAQ
Q:Your company is a trading company or a direct factory?
A:We are a direct factory which locates in Zhangjiagang city.
Q:All of your products are made by yourself or compacted via purchasing the others?
A:We have independent technical team who focus on making machines,all the products are made by our technical team.
Q:What is the ability of your factory?
A:About 80 lines per year.
Q:Do you have any other services about your products?
A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.
Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients should be satisfied first.
